This is just the logs only.
Single Side Fireplaces | ||||
Set Size | Model # | Certified Models | Weight (lbs) |
# of Logs in Set |
21" | CTS2108RG | ANSI/RGA2/72 | 12 | 8 |
24" | CTS2409RG | ANSI/RGA2/72 | 15 | 9 |
30" | CTS3010RG | ANSI/RGA2/72 | 20 | 10 |
36" | CTS3611RG | ANSI/RGA2/72 | 20 | 11 |
Vented Burner System Sheet | ||||
Natural Gas |
Burner System |
Certification | Weight | BTU | Compatible Log Size |
Size | 21" |
18" E-Burner |
(R)RGA2/72 (C)ANSI Z.21.60 |
32 | 70,000 | 18" - 21" |
18" H-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 32 | 70,000 | 18" - 21" |
18" Hidden Control Burner | ANSI Z21.60 | 29 | 70,000 | 18" - 21" |
Size | 24" |
24" E-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 39 | 80,000 | 24" |
24" H-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 39 | 80,000 | 24" |
24" Hidden Control Burner | ANSI Z21.60 | 32 | 80,000 | 24" |
Size | 30" |
30" E-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 40 | 90,000 | 30" |
30" H-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 40 | 90,000 | 30" |
30" Hidden Control Burner | ANSI Z21.60 | 39 | 90,000 | 30" |
Size | 36" |
36" E-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 53 | 100,000 | 36" |
36" H-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 53 | 100,000 | 36" |
36" Hidden Control Burner | ANSI Z21.60 | 53 | 100,000 | 36" |
Propane |
Burner System |
Certification | Weight | BTU | Compatible Log Size |
Size | 21" |
18" E-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 32 | 46,000 | 18" - 21" |
18" H-Burner System | (R)RGA2/72 (C)ANSI Z.21.60 | 32 | 46,000 | 18" - 21" |
18" System 4 Burner | ANSI Z.21.60 | 29 | 47,000 | 18" - 21" |
18" Hidden Control Burner | ANSI Z21.60 | 29 | 55,000 | 18" - 21" |
Size | 24" |
24" E-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 39 | 63,000 | 24" |
24" H-Burner System | (R)RGA2/72 (C)ANSI Z.21.60 | 39 | 63,000 | 24" |
24" System 4 Burner | ANSI Z.21.60 | 32 | 60,000 | 24" |
24" Hidden Control Burner | ANSI Z21.60 | 32 | 65,000 | 24" |
Size | 30" |
30" E-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 40 | 78,000 | 30" |
30" H-Burner System | (R)RGA2/72 (C)ANSI Z.21.60 | 40 | 78,000 |
30" |
30" System 4 Burner | ANSI Z.21.60 | 36 | 68,000 | 30" |
30" Hidden Control Burner | ANSI Z21.60 | 39 | 75,000 | 30" |
Size | 36" |
36" E-Burner | (R)RGA2/72 (C)ANSI Z.21.60 | 53 | 79,000 | 36" |
36" H-Burner System | (R)RGA2/72 (C)ANSI Z.21.60 | 53 | 79,000 |
36" |
36" System 4 Burner | Non-Certified | 40 | 90,000 | 36" |
36" Hidden Control Burner | ANSI Z21.60 | 53 | 85,000 | 36" |
